GE Fanuc IC200MDL742D power supply

The GE Fanuc IC200MDL742D is a 32‑point discrete output module (VersaMax series) that operates on 24 VDC positive logic and delivers up to 0.5 A per channel. Common failure modes include input voltage sag or spikes, internal regulator overheating, burnt output transistors or protection diodes, and insulation breakdown between the 18–30 VDC supply rail and ground. First‑check diagnostics should verify that the module receives a stable 24 VDC supply (±5 %), confirm each output channel’s continuity to ground and correct logic level with a multimeter, and visually inspect for scorch marks or swollen capacitors on the board.[oss-gpt-20b] Post Comment
