Graphtec FC5100 091001A Main Board
 |
The Graphtec FC5100 PR091001A is a main control board for the FC5100 vinyl cutter series, handling motion control, power distribution, and firmware execution. Common failure modes include burned or tripped MOSFETs on the motor driver section, damaged capacitors in the power supply rail, and loose or corroded I/O connectors that can cause intermittent communication with the host PC. Initial diagnostics should verify 24 V DC input to the board, inspect for visible component damage or overheating, and check all serial/USB connections for proper handshake and error codes reported by the cutter’s firmware.[oss-gpt-20b] |
