Pyramid PS-26KX regulated power supply Repair Service

Professional diagnostic and board-level repair service for this Pyramid PS-26KX regulated power supply.

The Pyramid PS‑26KX is a 25 A linear regulated DC power supply that uses an LM723 voltage regulator and multiple high‑power series‑pass transistors in parallel to deliver up to 15 V output. Common failure points include the LM723 IC (over‑voltage protection circuitry can trip), the pass transistor array (burnt or overheated junctions), and the input filtering capacitors that may sag under load. First‑check diagnostics should verify the AC input voltage and power cord integrity, measure the regulated output with a calibrated meter while monitoring for sudden drops or over‑voltage trips, and inspect the LM723 pinout and pass transistor junction temperatures for signs of failure. Post Comment

Need your Pyramid PS-26KX regulated power supply repaired?

Ship your unit to our North Carolina repair shop for component-level diagnostics and a repair estimate. We service industrial control electronics and power systems nationwide.

• ⚙️ Board-level diagnostics – Troubleshooting beyond simple module replacement
• 🔁 Clear approval process – No repair begins without your approval
• 🧰 Expert Technicians – Decades of board-level experience
• ✅ 1-Year Warranty – Included with completed repairs

Start a Repair Request   Call 1-336-969-0110

Nationwide service • Industrial-grade testing • 1-year warranty on completed repairs
