PaceMaster 501009 Rev.F Treadmill Board

PaceMaster 501009 Rev.F is a motor‑control power board used on Gold Elite and Platinum treadmill models to drive the lower motor and provide status LEDs. Known failure modes include loss of LED illumination despite an energized main supply—often caused by a blown regulator, damaged driver ICs (e.g., PWM controller), or cracked PCB traces near the LED drivers. First‑check steps: verify 24 V DC input voltage and polarity; inspect for visible burn marks or swollen components on the board; test continuity of the LED driver traces and confirm that the power supply output remains stable under load.[oss-gpt-20b]

Need your PaceMaster repaired or tested?

We specialize in the repair and refurbishment of high-end industrial control electronics and power systems like this unit.

⚙️ Fast Diagnostics – Same-day evaluation available
🔁 Reliable Turnaround – Most jobs ship within 5–10 business days
🧰 Expert Technicians – Decades of board-level experience
✅ 1-Year Warranty – Every repair fully guaranteed

📞 Call Now: 1 (336) 969-0110

Free Estimates • Industrial-grade testing • Nationwide Service
