The Tokyo Seimitsu E‑PV15D100 is an AP‑4000 series AC power‑controlled valve controller rated 85–250 V AC, typically used to drive pneumatic or hydraulic valves in process automation.

Common failure points for this unit include burnt or degraded MOSFETs and gate drivers on the high‑side driver board, failure of the internal optocoupler or relay contacts, and capacitor electrolyte leakage or cracking. Over‑voltage spikes from the valve side can also damage the isolation transformer and control IC.

First‑check diagnostics: verify that the input power supply is within spec (85–250 V AC, correct frequency) and that the output voltage to the valve matches the setpoint; inspect the PCB for burnt components or cracked solder joints; and review any error codes displayed on the controller’s indicator panel or logged in the host PLC.[oss-gpt-20b]
