Raymond AU3503 controller Repair Service

Professional diagnostic and board-level repair service for this Raymond AU3503 controller.

Raymond AU3503 is a 36‑48 V, up to 450 A AC motor speed controller used in industrial forklifts and heavy‑equipment applications. Common failure points include the high‑current MOSFET array, gate driver ICs, and power‑stage capacitors; overheating or thermal runaway often triggers over‑temperature shutdowns. First‑check diagnostics: verify that the input supply voltage is within spec and that the main output terminals are not shorted; inspect the board for burnt components, cracked solder joints, or excessive heat marks; review any error codes or status LEDs on the controller’s diagnostic port to pinpoint fault sources. Post Comment

Need your Raymond AU3503 controller repaired?

Ship your unit to our North Carolina repair shop for component-level diagnostics and a repair estimate. We service industrial control electronics and power systems nationwide.

• ⚙️ Board-level diagnostics – Troubleshooting beyond simple module replacement
• 🔁 Clear approval process – No repair begins without your approval
• 🧰 Expert Technicians – Decades of board-level experience
• ✅ 1-Year Warranty – Included with completed repairs

Start a Repair Request   Call 1-336-969-0110

Nationwide service • Industrial-grade testing • 1-year warranty on completed repairs

Owner-Operated • Practical Pricing • 1-Year Warranty • Nationwide Service
