Dynamote Service & Repair Forum

Hi AJ: There is a female 6 connector plug You need to momentery short out two of the wires. If you want to give me a call I will give you more information. 904-733-9242 or email me.

— Posted by Ray Mills on 2007-07-18

Reply🗨️Ask a New Question Below❓

If you need your Dynamote unit tested or repaired,
give us a call at 1-336-969-0110.
We offer fair estimates and extended warranties on the work performed.
Shipping/Receiving:
Industrial Electronic Repair
145 Rockwell Place Ct
Tobaccoville, NC 27050
Phone: 1-336-969-0110

Recent 27 Comments

#Dynamote by Dwayne Lange - Sunspot Solar on 2005-10-18 01:33

I am a solar power supplier / installer located in Adelaide, Australia.I have had a client bring in a \"Bravo\" QBC 1012 inverter / charger manufactured by Dynamote Corporation.My local inverter repairer is unable to find any specs on these products, but has been able to confirm that the M...
Show More

#Dynamote by Bill on 2006-03-04 12:15

can you tell me the correct fuses for my power invertermodel# A20-50D

#Dynamote by RYAN WILSON on 2006-06-15 15:04

HAVING A PROBLEM WITH POWER GOING IN, BUT NO POWER COMING OUT. POSSIBLY SOLENOID? MODEL # A40-120A/150

#Dynamote by Ty Cummins on 2006-09-16 04:52

need to see if you would have a wiring diagram for installation for a dynamote inverter model number a30 70b any help would be great. thanks for your time. Ty

#Dynamote by Lloyd Morris on 2006-10-03 15:01

A customer brought me a Dynamote President B10-KKK Inverter It trips the reset as soon as you connect 12 volt power to it . I suspect the diodes are fried but have no schematic or anything to help. can you be of assistance?

#Dynamote by Barry Coker on 2006-11-03 20:22

I am looking for a diagram to hook up a Dynamote Model#A40-120Serl.#811734. This unit is on a 1981 Mack fire truck The trucks eng.was just rebuilt and the inverter didnot work when the truck was picked up. I have no diagrams to Know if I have power at all points needed onthe D C side. Your help woul...
Show More

#Dynamote by eric on 2006-12-18 01:04

I bought it used ,it works but I would like to know what output wattage it has.I tried to run 2 - 500 watt lights and it would not do it,then I ran a 75 watt bulb on a full charged 1000amp batt.,It ran 37min then tripped low voltage.I recharged the battery, hooked it it to an APC battery backup (100...
Show More

#Dynamote by Ajendra Prasad on 2007-05-07 20:45

Hi , I have a Dynamote power inverto model # B10KKK-TINPUT 14.2 VDCOUTPUT 120VAC10AMPS 60HZMy invertor doesnt come on at all, I have done some test on power supply from battery to circuit breaker and have got 14v there but after the tranformer there is no out put , this unit has a remote connection ...
Show More

#Dynamote by Ajendra Prasad on 2007-05-07 20:50

Hi , I have a Dynamote power inverto model # B10KKK-TINPUT 14.2 VDCOUTPUT 120VAC10AMPS 60HZMy invertor doesnt come on at all, I have done some test on power supply from battery to circuit breaker and have got 14v there but after the tranformer there is no out put , this unit has a remote connection ...
Show More

#Dynamote by DENNIS BERNARD on 2007-06-27 21:41

i have a dynomote m a60-120 sn-810189 12 dc system i need to know how to wire my delco remy alternator into it.the alternator model is 111740 s/n 801122 type 150 amps 145.please help. this is for a fire truck and is out of service.thanx

#Dynamote by Ray Mills on 2007-07-18 00:48

Hi AJ: There is a female 6 connector plug You need to momentery short out two of the wires. If you want to give me a call I will give you more information. 904-733-9242 or email me.

#Dynamote by James Beaman on 2007-07-28 14:02

Any and info including schematics if that is possible. We would like to use in the field. Thanks, James

#Dynamote by Joel Moorman - Moorman Electric on 2007-11-26 19:52

Is it possible to obtain a service manual for a Dynamote A30-70D option LD/GF120? Only 40V output and stop button does not shut unit off. Also need a green connector sleeve. If you could help us out, it would be greatly appreciated. Looking forward to hearing from you. Thank You, Joel Moorman Moorma...
Show More

#Dynamote by Harry Trottier on 2008-01-16 17:38

Is it possible to get a manual for a Dynamote A/L25-120 Inverter?

#Dynamote by Mitchell Vavra on 2008-02-14 14:24

I bought a used Derrick Digger body, and it has a A60-120D with options/LD/GFI120. The wires were cut off the old chassis and I am currious on how to correctly connect them to my Chassis. Any help would be appriciated.Thanks,Mitch Vavra

#Dynamote by Tina Gilbert on 2008-07-24 14:16

Wiring instructions needed for remote. Can you assist me?

#Dynamote by steve bosco on 2009-10-24 17:37

I have this inverter but no manual to install it. can you help me find the paperwork to properly connect this unit? the wires are cut but I have know idea how to connect it to my vehicle.

#Dynamote by James R Pacenti on 2009-11-14 19:58

The electrical system was modified by dynamote, sticker said to contact dynamote before makeing any repairs. need to know where the voltage regulator has been located. the vehicle is a 1989 bucket truck.

#Dynamote by richard on 2010-01-21 18:49

A friend of mine aquired an inverter that can be installed to a vehicle. when it was found in a box in an old barn,the box and the instructions inside, have deteriorated. Is there anyway to find the manuel.

#Dynamote by Ed Cook on 2010-02-09 00:23

I purchase a 1980 Amblance E-350 Ford It has a Power Gaurd Mod. G-B10-10 Ser# 79213 it is on top of Dynamote 1.0 KVAMod. # B10-KKK Ser.# 800226 It is not connected any more to the truck can you send my the instruction manual of it use and connection instruction. If you can help me I baught it for my...
Show More

#Dynamote by RUSSELL LEYRA on 2010-09-07 11:52

GOOD MORNING, I AM LOOKING FOR SOME PRICING ON A REPAIR OR REPLACEMENT FOR A CUSTOMER\'S DYNAMOTE A40-120D/240.I AM NOT SURE WHAT IS WRONG WITH THE UNIT OTHER THAN IT DOES NOT WORK. THANK-YOU FOR YOUR TIME RUSS

#Dynamote by Dan Harding on 2010-12-06 22:25

Can I get a manual and wiring diagram for this unit? Our fire dept. just bought a used rescue truck with a unit on it.

#Dynamote by Jimmie Morgan on 2015-03-05 18:01

In a fire truck we bought Puts out about 40 volt Ac Mfg 1995 Want to know if fixable. Thanks Jim Goodman Area Fire Protection District

#Dynamote by AHMED on 2015-03-07 08:15

the wiring diagram and asking about the out put Ac 220 sine wave and asking of the sine wave does it was pure sine wave or not ?

#Dynamote by David Wardle on 2015-12-31 19:54

Do you service Dynamote Static Inverters or possibly have a schematic for this unit: Dynamote Brutus TB32-24. Described as : 3200 watt, 24 volt battery powered inverter, hybird hi-low frequency.......high frequency H bridge feeding 60 Hz. transformerThanks, David

#Dynamote by Julia Lunstra on 2022-07-18 02:22

My husband recently passed away and while cleaning the garage I came across this item. It is a Dynamote B20-12 with CD, LVCO. What is it? What is it good for? How much is it worth for me to sell?Any help that you could provide would be extremely appreciated.julia

#Dynamote by James Wooldridge on 2024-11-26 06:25

Trying to wire the remote switch inverters not working without it
