Dear Greg Appleby,I undeerstood you might have documentation of EL.GE drives. I need a electrical diagram for the connection of the following type:EL.GE SD CC 200/49/120It\'s a DC driveBest regards,Daniel Zijlmans

— Posted by DANIEL ZIJLMANS on 2007-12-18

Reply🗨️Ask a New Question Below❓

If you need your El.Ge unit tested or repaired,
give us a call at 1-336-969-0110.
We offer fair estimates and extended warranties on the work performed.
Shipping/Receiving:
Industrial Electronic Repair
145 Rockwell Place Ct
Tobaccoville, NC 27050
Phone: 1-336-969-0110

Recent 22 Comments

#El.Ge by Sean Moffatt on 2007-01-02 22:44

I have one of these units in a servo roll feed that drives the brushed DC servo motor just fine. The problem is that it does not respond to the +/- 10V control signal. It runs at 100% randomly in fwd or rev when a start signal is applied. The cnc controller was made in the 80\'s It is no longwer sup...
Show More

#El.Ge by Leonard Van den Berg on 2007-04-18 12:00

Dear Sir,I\'ve bought 3 second hand servo drives, EL.GE AZE-CC4Q Tipo AZE LV15/AO-PI am looking for a few weeks for a diagram to connect these, but can\'t find anything. As well i like to know what is the input voltage.Kind regards,Leonard van den Berg

#El.Ge by Greg Appleby on 2007-05-25 13:56

Any results on your search?I have a lot of documentation but it is in French + some in Italian).I bought a second hand drice ex France.are your units branded LV15 or perhaps LV12??pls email me .. we may be of help to each other.Greg Appleby

#El.Ge by Andrea on 2007-08-01 11:49

We have a old machine with this type of electrical device ,but at the moment it\' s stopped because i have some wrong signal coming (i think)from servo motor D.C AZE LV15 .when the \"speed enable\" signal it\'s sended to AZE device it rest only for a few second and then fall down, this hap...
Show More

#El.Ge by Miki gasic on 2007-08-25 20:25

i have a damaged servo drive and i need to get it repaired

#El.Ge by DANIEL ZIJLMANS on 2007-12-18 13:39

Dear Greg Appleby,I undeerstood you might have documentation of EL.GE drives. I need a electrical diagram for the connection of the following type:EL.GE SD CC 200/49/120It\'s a DC driveBest regards,Daniel Zijlmans

#El.Ge by Dag A on 2008-02-19 21:29

Is there anybody who has a user manual or electric wiring diagram or some information at all on this servodrive ?All help will be very much appreciated ....Best regards Dag ANorway

#El.Ge by Greg Appleby on 2008-06-27 11:53

I posted back in 2007. I now have some docmentation includingelectrical diagrams.I can be contacted bee@bee.com.au

#El.Ge by MARKO on 2008-10-16 12:45

I NEED COMPLET DC SERVODRIVE EL.GE AZE-CC4Q.PLEASE SEND ME OFFER.

#El.Ge by jeff wu on 2008-11-07 01:21

Holle !MY DC SERVODRIVE IS NOT GOOD.SO MY MACHINE NOT WORKPARTS : DC SERVODRIVETYPE : AZE-CC4Q1.HOW MONERY ,NEW PARTSTHANKS ! JEFF . 2008.11.07

#El.Ge by John Aland on 2009-02-24 04:00

Hi, I have a customer with several of these drive units not working.Would it be possible to get these units repaired, at what cost per unit, freight to Australia and turn arround time.Kindest Regards,John.

#El.Ge by Ing. Jose Calos Pinto on 2009-03-02 17:06

Estimados, tengo que reparar una maquna giben con un controlador AZE-CC4Q, esto es en bolivia, pero no hay informaion aerca de la plaza y su funcionamiento para la secuencia de trabajo, favor ayudarme con este dilema

#El.Ge by Ing. Jose carlos Pinto Aranibar on 2009-03-04 12:54

Estimados señores, estamos reparando una seccionadora de madera de giben, cuenta con una placa AZE CC4Q, no sabemos si esta esta bien o mal, les rogaria puedan facilitarnos los pasos a seguir o la secuencia de las entradas o si tubieran un data sheet de está tarjeta, para ver si podemos hacerla func...
Show More

#El.Ge by Henry Guillemin on 2009-06-22 03:19

Can you please supply a quote to repair this drive for us. Do you have any repair agents in Auckland NZBest regardsHenry

#El.Ge by josep on 2009-07-28 22:57

Hi.I bought a old cnc mill whit this driver but one is dead.I need the schematics for repair,mny tks, Josep

#El.Ge by pouyan on 2009-11-11 12:05

dear siri need the aze-cc4q catalog for LED description and pinoutbest regardspouyan

#El.Ge by Sven Rookie on 2010-04-20 19:33

I\'v a question regarding the controller:Are there any spare parts for those drives, is there any technical support existing or is there any identical drive which can be used?As USA is quite far away - do you know a technical support in europa?Many thanks for your answer!Kind regardsSven

#El.Ge by mick Sharman on 2010-04-28 06:53

There are no spares anywhere. The Poletti & Osta brand is the same, just badged and coloured differently. They are the same as El.ge. identical.You can exchange any higher current rating (average and Peak) as long as it is higher rated, but same Voltage. I could not find any of these, but there ...
Show More

#El.Ge by Vlade Vujovic on 2010-10-20 12:41

Molim Vas za pomoc,imam cnc morbideli u 15 i ne radi mi DC servodrive Y osa,type AZE-cc4q el.ge,Milano.tipo AZE HV 12/AO-R-200/6,5/18N`MATR EC 19613 CODICE 16/88Interesuje me da li imate i kolika je cena?pozdrav i hvala,Vlade

#El.Ge by Alberto Tavares on 2011-02-11 10:13

nesecito por favor del manual de lo variador SD/CC 4º S

#El.Ge by Ana Gomes on 2012-04-02 11:53

Good afternoon,Can you please send me price and availability of part AZE-CC4Q please?Thank you very much for your time.

#El.Ge by AmalleyGekmab on 2013-03-07 16:05

When i utilized to obtain high on life but lately I\'ve accumulated a amount of resistance.
